จำหน่าย ZOOM F3 เครื่องบันทึกเสียงแบบพกพา 2 อินพุต
Features
  • 2-channel / 2-track field audio recorder
  • Featuring 32-bit float recording and dual AD converters for full dynamic range and clip-free audio capture
  • 2 discrete inputs with locking XLR connectors
  • Input signals can be monitored with realtime waveform display on LCD
  • Compact and Durable (can be attached to boom mic with velcro)
  • High quality mic preamps provide a super-low noise floor (−127 dBu EIN)
  • Record up to 192 kHz sampling/32-bit float WAV format, mono or stereo files
  • Stereo ⅛" Phone/Line Output jack with dedicated Volume control
  • Records directly to microSDHC and microSDXC cards up to 1 TB
  • Wireless iOS/Android* remote control available through optional BTA-1 Bluetooth adapter (*Android version to be released in 2022)
  • Use as 2-in/2-out USB audio interface (up to 32-bit float/96 kHz)
  • Over 8 hours of operation with two AA alkaline batteries
  • Runs on only 2 standard AA batteries or AC adapter (AD-17) or USB battery pack
  • Wireless timecode synchronization (*Optional BTA-1 Bluetooth adapter and UltraSync Blue device by Timecode Systems are required.)
Tech Specs

Input and output channels

INPUTS MIC/LINE (mono): 2
OUTPUTS LINE OUT: 1
  PHONE OUT: 1

Inputs

MIC/LINE (MONO) Connectors: 2 XLR (2: HOT)
  Input gain: Adjustment unnecessary (dual AD converter circuits used)
  Input impedance: MIC: 3 kΩ or more
    LINE: 3 kΩ or more
  Maximum input level: MIC: +4 dBu
    LINE: +24 dBu
  Phantom power: +24/48 V
    Combined channel total of 10 mA or less
  Equivalent input noise: −127 dBu or less (IHF-A) when waveform magnification is ×1024 with 150 Ω input

Outputs

LINE OUT Connector: 1 stereo mini jack
  Maximum output level: +1 dBu
  Output impedance: 100 Ω or less
PHONE OUT Connector: 1 stereo mini jack
  Maximum output level: 50 mW + 50 mW (into 32 Ω load)
  Output impedance: 15 Ω or less

Recorder

  Maximum simultaneous recording tracks: 2
  Maximum simultaneous playback tracks: 2
  Recording format: WAV
    44.1/48/ 88.2/96/192 kHz,
    32-bit float mono/stereo
    BWF and iXML formats supported
  Recording media: 4 – 32 GB cards compatible with the microSDHC specification
    64 GB – 1 TB cards compatible with the microSDXC specification

Display

    LCD with backlight (96×64 resolution)

USB

  Connector: USB Type-C
    • Use a USB cable that supports data transfer. USB bus power is supported.
  Audio interface operation: USB2.0 High Speed
    44.1/48/88.2/96 kHz, 24-bit linear/32-bit float
    • 32-bit float format is supported for firmware version 2.0 or later.
    2-in/2-out
  Mass storage operation: USB 2.0 High Speed

REMOTE

    Dedicated wireless adapter (ZOOM BTA-1)

POWER

    2 AA batteries (alkaline, NiMH or lithium)
    AC adapter (ZOOM AD-17): DC 5 V/1 A
    • USB bus power is supported.
ESTIMATED CONTINUOUS OPERATION TIME USING BATTERIES 48 kHz/32-bit float, 2ch recording to microSDHC card Alkaline batteries: about 8 hours NiMH batteries (1900 mAh): about 8.5 hours Lithium batteries: about 18 hours
• THE VALUES ARE APPROXIMATE. (without headphones, PHANTOM off, LCD Backlight off) Alkaline batteries: about 2 hours
• CONTINUOUS BATTERY OPERATION TIMES WERE DETERMINED USING IN-HOUSE TESTING METHODS. 48 kHz/32-bit float, 2ch recording to microSDHC card NiMH batteries (1900 mAh): about 3 hours
THEY WILL VARY GREATLY ACCORDING TO USE CONDITIONS. (headphones into 32Ω load, PHANTOM at 48 V (5 mA), LCD Backlight off) Lithium batteries: about 7.5 hours
POWER CONSUMPTION: 5 W maximum
DIMENSIONS: 75.0 mm (W) × 77.3 mm (D) × 47.8 mm (H)
WEIGHT: (including batteries) 242 g
NOTE: 0 DBU = 0.775 VRMS
