Transmitter (TX)
|
Wireless Band |
2400 ~ 2483.5MHz |
|
Transmitting Power |
+10dBm |
|
Receiving Sensitivity |
-86dBm |
|
Antenna |
PCB Antenna |
|
Polar Pattern |
Omnidirectional |
|
Frequency Response |
80Hz ~ 20kHz |
|
Sound Delay |
<20ms |
|
External Mic Input Interface |
3.5mm TRS |
|
Battery |
Built-in Li-ion Battery 300mAh 3.7V |
|
Battery Life |
5 Hours |
|
Net Weight |
29g |
|
Dimension |
39 x 22 x 55mm |
|
Operating Temperature |
0℃ ~ 50℃ |
Receiver (RX)
|
Wireless Band |
2400 ~ 2483.5MHz |
|
Transmitting Power |
+10dBm |
|
Receiving Sensitivity |
-86dBm |
|
Antenna |
PCB Antenna |
|
Audio Output Amplitude |
+0dB ~ +12dB |
|
Sound Delay |
<20ms |
|
Audio Output Interface |
3.5mm TRS |
|
Monitor Interface |
3.5mm TRS/TRRS |
|
Battery |
Built-in Li-ion Battery 300mAh 3.7V |
|
Battery Life |
5 Hours |
|
Net Weight |
29g |
|
Dimension |
39 x 22 x 55mm |
|
Operating Temperature |
0℃ ~ 50℃ |
UC Receiver (UC RX)
|
Wireless Band |
2400 ~ 2483.5MHz |
|
Transmitting Power |
+10dBm |
|
Receiving Sensitivity |
-86dBm |
|
Antenna |
PCB Antenna |
|
Audio Output Amplitude |
+0dB ~ +12dB |
|
Sound Delay |
<20ms |
|
Date Interface |
USB-C |
|
Monitor Interface |
3.5mm TRS/TRRS |
|
Net Weight |
29g |
|
Dimension |
39 x 22 x 55mm |
|
Operating Temperature |
0℃ ~ 50℃ |
