| System |
|
| Wireless Transmission |
Digital 5.8 GHz |
| Number of RF Channels |
4 |
| Included Transmitters |
1 x Bodypack with Microphone |
| Diversity |
Non-Diversity |
| Max Operating Range |
60 m / 196.9′ (Line of Sight) |
| Max Systems per Setup |
3 |
| Latency |
|
| Encryption |
None |
| Modulation |
|
| Receiver |
|
| Form Factor |
Camera-Mount |
| Mounting Options |
Shoe-Mount (with Included Hardware) |
| Antenna |
1 x Internal |
| Number of Audio Channels |
1 |
| Audio I/O |
1 x 1/8″ / 3.5 mm TRS Female Unbalanced Mic Output (Lockable) |
| Audio Output Level |
-60 dBV |
| Frequency Response |
20 Hz to 20 kHz |
| USB/Lightning Connectivity |
1 x USB Type-C (Bus Power, Charging) |
| Power Requirements |
Battery or Bus Power (USB) |
| Battery Type |
1 x Built-In Rechargeable |
| Approx. Battery Life |
6 Hours |
| Display & Indicators |
1 x LED (Power) |
| Operating Temperature |
0 to 50°C / 32 to 122°F |
| Storage Temperature |
-20 to 55°C / -4 to 131°F |
| Dimensions |
11.4 x 2.8 x 3 cm / 4.5 x 1.1 x 1.2″ |
| Weight |
85 g / 3 oz |
| Transmitter |
|
| Form Factor |
Bodypack |
| RF Output Power |
10 mW |
| Audio I/O |
1 x 1/8″ / 3.5 mm TRS Female Unbalanced Input (Lockable) |
| Included Cable Connector |
1/8″ / 3.5 mm TRS |
| Pad |
None |
| Muting |
None |
| Auto-Level Control |
No |
| Signal Processing |
None |
| Frequency Response |
20 Hz to 20 kHz (Dependent on Mic) |
| Sync Method |
Proprietary |
| Antenna |
1 x Internal |
| Power Requirements |
Battery or Bus Power (USB) |
| Battery Type |
1 x Built-In Rechargeable |
| Approx. Battery Life |
6 Hours |
| USB/Lightning Connectivity |
1 x USB Type-C (Bus Power, Charging) |
| Display & Indicators |
1 x LED (Power) |
| Operating Temperature |
0 to 50°C / 32 to 122°F |
| Storage Temperature |
-20 to 55°C / -4 to 131°F |
| Dimensions |
11.4 x 2.8 x 3 cm / 4.5 x 1.1 x 1.2″ |
| Weight |
85 g / 3 oz |
| Microphone |
|
| Form Factor |
Lavalier |
| Color |
Black |
| Sound Field |
Mono |
| Operating Principle |
Pressure Operated |
| Capsule |
Electret Condenser |
| Polar Pattern |
Omnidirectional |
| Frequency Range |
20 Hz to 18 kHz |
| SNR |
58 dB |
| Maximum SPL |
110 dB SPL |
| Sensitivity |
-40 dBV/Pa at 1 kHz |
| Output Connectors |
1 x 1/8″ / 3.5 mm TRS Male Unbalanced (Lockable) |
| Cable Length |
180.1 cm / 70.9″ |
| Operating Temperature |
-20 to 60°C / -4 to 140°F |
| Diameter |
4 mm / 0.2″ |
